perma AU
Accessories

Heavy Duty Kits - 500cc

Heavy Duty installation kits have been specifically designed for use in operational areas which are subject to regular wash down and water impact, such as the conditions found in coal handling preparation plants. The installation kits are highly versatile and can be adapted for attachment to beam sections and square mesh safety cages. The bracket systems included in Heavy Duty installation kits are fabricated in Australia from stainless steel.

Heavy Duty installation kits include lubricator covers and manual purge kits for each lubrication point along with a range of commonly required fittings, push-lock swivel hose ends and high quality Duffield brand hose with 3/8" internal diameter.

The range of Heavy Duty kits with beam clamps includes options for 1, 2, 3 or 4 points. Beam clamp options include 30mm and 65mm sizes.

Heavy Duty 30mm beam mount installation kits

1 point Heavy Duty beam clamp installation kit
Art. No.: K130CX
More info

Content:

  • 1 x Heavy Duty 2 point bracket
  • 2 x 30mm beam clamp
  • 1 x Support flange
  • 1 x Manual purge kit
  • 1 x Heavy Duty full length cover
  • 2.0 mtrs of 3/8" ID grease line
  • 2 x Hose ends
  • 1 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 1 x 1/4" BSPF to 1/4" BSPM adaptor
  • 1 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.

2 point Heavy Duty beam clamp installation kit
Art. No.: K230CX
More info

Content:

  • 1 x Heavy Duty 2 point bracket
  • 2 x 30mm beam clamp
  • 2 x Support flange
  • 2 x Manual purge kit
  • 2 x Heavy Duty full length cover
  • 4.0 mtrs of 3/8" ID grease line
  • 4 x Hose ends
  • 2 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 2 x 1/4" BSPF to 1/4" BSPM adaptor
  • 2 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.



3 point Heavy Duty beam clamp installation kit
Art. No.: K330CX
More info

Content:

  • 1 x Heavy Duty 3 point bracket
  • 2 x 30mm beam clamp
  • 3 x Support flange
  • 3 x Manual purge kit
  • 3x Heavy Duty full length cover
  • 6.0 mtrs of 3/8" ID grease line
  • 6 x Hose ends
  • 3 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 3 x 1/4" BSPF to 1/4" BSPM adaptor
  • 3 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.



4 point Heavy Duty beam clamp installation kit
Art. No.: K430CX
More info

Content:

  • 1 x Heavy Duty 4 point bracket
  • 2 x 30mm beam clamp
  • 4 x Support flange
  • 4 x Manual purge kit
  • 4 x Heavy Duty full length cover
  • 8.0 mtrs of 3/8" ID grease line
  • 8 x Hose ends
  • 4 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 4 x 1/4" BSPF to 1/4" BSPM adaptor
  • 4 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.

Heavy Duty 65mm beam mount installation kits

1 point Heavy Duty beam clamp installation kit
Art. No.: K165CX
More info

Content:

  • 1 x Heavy Duty 1 point bracket
  • 2 x 65mm beam clamp
  • 1 x Support flange
  • 1 x Manual purge kit
  • 1 x Heavy Duty full length cover
  • 2.0 mtrs of 3/8" ID grease line
  • 2 x Hose ends
  • 1 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 1 x 1/4" BSPF to 1/4" BSPM adaptor
  • 1 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.



2 point Heavy Duty beam clamp installation kit
Art. No.: K265CX
More info

Content:

  • 1 x Heavy Duty 2 point bracket
  • 2 x 65mm beam clamp
  • 2 x Support flange
  • 2 x Manual purge kit
  • 2 x Heavy Duty full length cover
  • 4.0 mtrs of 3/8" ID grease line
  • 4 x Hose ends
  • 2 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 2 x 1/4" BSPF to 1/4" BSPM adaptor
  • 2 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.



3 point Heavy Duty beam clamp installation kit
Art. No.: K365CX
More info

Content:

  • 1 x Heavy Duty 3 point bracket
  • 2 x 65mm beam clamp
  • 3 x Support flange
  • 3 x Manual purge kit
  • 3x Heavy Duty full length cover
  • 6.0 mtrs of 3/8" ID grease line
  • 6 x Hose ends
  • 3 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 3 x 1/4" BSPF to 1/4" BSPM adaptor
  • 3 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.



4 point Heavy Duty beam clamp installation kit
Art. No.: K465CX
More info

Content:

  • 1 x Heavy Duty 4 point bracket
  • 2 x 65mm beam clamp
  • 4 x Support flange
  • 4 x Manual purge kit
  • 4 x Heavy Duty full length cover
  • 8.0 mtrs of 3/8" ID grease line
  • 8 x Hose ends
  • 4 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 4 x 1/4" BSPF to 1/4" BSPM adaptor
  • 4 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.



Heavy Duty cage mount installation kits

1 point Heavy Duty cage hanger installation kit
Art. No.: K1CHCX
More info

Content:

  • 1 x Heavy Duty 1 point bracket
  • 2 x Cage hanger arms
  • 1 x Support flange
  • 1 x Manual purge kit
  • 1 x Heavy Duty full length cover
  • 2.0 mtrs of 3/8" ID grease line
  • 2 x Hose ends
  • 1 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 1 x 1/4" BSPF to 1/4" BSPM adaptor
  • 1 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.



2 point Heavy Duty cage hanger installation kit
Art. No.: K2CHCX
More info

Content:

  • 1 x Heavy Duty 2 point bracket
  • 2 x Cage hanger arms
  • 2 x Support flange
  • 2 x Manual purge kit
  • 2 x Heavy Duty full length cover
  • 4.0 mtrs of 3/8" ID grease line
  • 4 x Hose ends
  • 2 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 2 x 1/4" BSPF to 1/4" BSPM adaptor
  • 2 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.



3 point Heavy Duty cage hanger installation kit
Art. No.: K3CHCX
More info

Content:

  • 1 x Heavy Duty 3 point bracket
  • 2 x Cage hanger arms
  • 3 x Support flange
  • 3 x Manual purge kit
  • 3 x Heavy Duty full length cover
  • 6.0 mtrs of 3/8" ID grease line
  • 6 x Hose ends
  • 3 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 3 x 1/4" BSPF to 1/4" BSPM adaptor
  • 3 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.



4 point Heavy Duty cage hanger installation kit
Art. No.: K4CHCX
More info

Content:

  • 1 x Heavy Duty 4 point bracket
  • 2 x Cage hanger arms
  • 4 x Support flange
  • 4 x Manual purge kit
  • 4 x Heavy Duty full length cover
  • 8.0 mtrs of 3/8" ID grease line
  • 8 x Hose ends
  • 4 x 90 deg elbow 1/4" BSPF to 1/4" BSPM
  • 4 x 1/4" BSPF to 1/4" BSPM adaptor
  • 4 x 1/4" BSPF to 1/8" BSPM adaptor

*max working pressure 28 bar. Minimum burst pressure 112 bar.
